Availability: | |
---|---|
KVVRP,KYJVRP,KVVRP-22,KYJVRP-22,KVVRP-32,KYJVRP-32
XITE
8544492100
Copper
450/750V
XLPE or PVC
PVC/PE/LSZH/FR
SWA ,STA or Unarmored
Flame Retardant, Antiflaming, Fire resistance, LSZH
![]() |
Conductor: single strand copper wire or stranded oxygen-free copper wire
Product Features:
Rated voltage: 450 / 750V or 0.6/1 kv
The working temperature: ordinary type does not exceed 70 ℃, flame retardant does not exceed 105 ℃
Insulation: PVC/XLPE
Sheath: PVC/PE/LSZH/FR
Color: black
Product standard:GB/T 9330-2008.
The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005,GB/T5023-2008,JB/T8734-2012.
Type | Name | Section Area(mm2) | No. of Core |
KVVRP | The control flexible cable of Copper conductor, PVC insulated, PVC sheathed, and braided shield by copper wire | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KYJVRP | The control flexible cable of Copper conductor, XLPE insulated, PVC sheathed, and braided shield by copper wire | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KVVRP-22 | The control flexible cable of Copper conductor, PVC insulated, PVC sheathed, braided shield by copper wire, and steel tape armoring | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KYJVRP-22 | The control flexible cable of Copper conductor, XLPE insulated, PVC sheathed, braided shield by copper wire, and steel tape armoring | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KVVRP-32 | The control flexible cable of Copper conductor, PVC insulated, PVC sheathed, braided shield by copper wire, and fine round steel wire armoring | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KYJVRP-32 | The control flexible cable of Copper conductor, XLPE insulated, PVC sheathed, braided shield by copper wire, and fine round steel wire armoring | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
This product is suitable for the control monitoring circuit of AC rated voltage U0/U of 450/750V and below and the connecting line of electrical instrument in protection circuit and power distribution device. It has good shielding effect and anti-interference effect.
control cable are suitable for the wiring of electrical controlling equipments and instrument,monitoring and controlling return circuit,electrical protection and measurement in power distribution unit under the
circumstance that the rated voltage is up to 450/750V AC. selection of high quality Control Cables includes flexible control cables and flexible automation cables.
These cables are supplied to a variety of industries and applications, including robotics, manufacturing, construction, power and distribution, and more. They are common in both commercial and industrial markets.
Cables with Low smoke zero halogen, fire resistance, flame-retardant is our advantage, we have National Patent Certificate on it.
We have CCC and ISO9001 certificate, we can accept ODM, OEM and also can accept personal customized.
![]() |
Conductor: single strand copper wire or stranded oxygen-free copper wire
Product Features:
Rated voltage: 450 / 750V or 0.6/1 kv
The working temperature: ordinary type does not exceed 70 ℃, flame retardant does not exceed 105 ℃
Insulation: PVC/XLPE
Sheath: PVC/PE/LSZH/FR
Color: black
Product standard:GB/T 9330-2008.
The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005,GB/T5023-2008,JB/T8734-2012.
Type | Name | Section Area(mm2) | No. of Core |
KVVRP | The control flexible cable of Copper conductor, PVC insulated, PVC sheathed, and braided shield by copper wire | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KYJVRP | The control flexible cable of Copper conductor, XLPE insulated, PVC sheathed, and braided shield by copper wire | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KVVRP-22 | The control flexible cable of Copper conductor, PVC insulated, PVC sheathed, braided shield by copper wire, and steel tape armoring | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KYJVRP-22 | The control flexible cable of Copper conductor, XLPE insulated, PVC sheathed, braided shield by copper wire, and steel tape armoring | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KVVRP-32 | The control flexible cable of Copper conductor, PVC insulated, PVC sheathed, braided shield by copper wire, and fine round steel wire armoring | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
KYJVRP-32 | The control flexible cable of Copper conductor, XLPE insulated, PVC sheathed, braided shield by copper wire, and fine round steel wire armoring | 0.75, 1.0, 1.5, 2.5,4,6 | 2c to 37 core |
10 | 2c to 14 core | ||
This product is suitable for the control monitoring circuit of AC rated voltage U0/U of 450/750V and below and the connecting line of electrical instrument in protection circuit and power distribution device. It has good shielding effect and anti-interference effect.
control cable are suitable for the wiring of electrical controlling equipments and instrument,monitoring and controlling return circuit,electrical protection and measurement in power distribution unit under the
circumstance that the rated voltage is up to 450/750V AC. selection of high quality Control Cables includes flexible control cables and flexible automation cables.
These cables are supplied to a variety of industries and applications, including robotics, manufacturing, construction, power and distribution, and more. They are common in both commercial and industrial markets.
Cables with Low smoke zero halogen, fire resistance, flame-retardant is our advantage, we have National Patent Certificate on it.
We have CCC and ISO9001 certificate, we can accept ODM, OEM and also can accept personal customized.
